Models 320
Detector Type 336 × 256 VOx Microbolometer
Video Refresh Rate <9Hz NTSC
Field of View (H x V) 17° × 13° NTSC
Focal Length 19mm Fixed Focus
Start up < 1.5 seconds
Waveband 7.5 - 13.5 μm
Thermal Sensitivity <50 mK @ f/1.0
Image Processing FLIR Proprietary Digital Detail Enhancement ™
User Interface
Splash Screen Generic
Power Button On/Off
Zoom Button 2X Zoom
Black Hot/White Hot BH/WH/InstAlert ™
Brightness Adjusts display Brightness Setting
Task Light LED Enabled during Power off state
System Specifications
Built-In Display 640 X 480 LCD Display
Video Output NTSC composite video (Switchable to PAL w/GUI) - 320 Model only
Image Polarity White Hot/Black Hot/InstAlert ™ ; Selectable
On-Screen Symbology Standard
Power
Battery Type Internal Li-Ion Cell
Battery Life (Operating) >5 Hours
Environmental
Rating IP-67, Submersible
Operating Temp. -4 ° F to 122 ° F (-20 ° C to 50 ° C)
Storage Temp. -40 ° F to 140 ° F (-40 ° C to 60 ° C)
Drop 1 m drop
Physical
Weight (incl. lens) 12 oz (340 g)
Size (L × W × H) 6.70" × 2.31" × 2.44"
Range Performance
Detect Man (1.8 m × 0.5 m) 600 yards (550m)
Physical
Packages Include Handheld Thermal Camera, USB Power Adapter/Charger, Wrist strap, Custom Video out cable (320 & 640 versions), USB Cable, Quick Start Guide, Molle bag
Analog Video Output? Yes
