PL76575K Free Skelontinized ADM Mount. Limited Supply!
Sensor 1024x768 @ 12 µm (NETD <35 mK) Objective lens F60 / 1.0
Magnification, x 2.5-20
Field of view (HxV), degrees / m@100m 11.7° / 20.5 m
Detection range, m 2800
Sensor
Type uncooled
Resolution, pixels 1024x768
Pixel pitch, µm 12
NETD, mK <35
Frame rate, Hz 50
Optics
Objective lens F60 / 1.0
Magnification, x 2.5-20
Field of view (HxV), degrees / m @ 100 m 11.7° / 20.5 m
Eye relief, mm 65
Display
Type AMOLED
Resolution, pixels 2560x2560
Range Performance
Detection range, m 2800
Laser Rangefinder
Safety class for laser equipment according to IEC 60825-1:2014 1
Wavelength, nm 905
Max. measuring range, m 800
|
