Sensor 640x480 pix. @ 17 µm (NETD <18 mK)
Objective lens F50 / 1.0
Magnification, x 2.5-10 (x4 digital zoom)
Field of view (HxV), degrees / m@100m 12.4x9.3 / 21.8x16.3
Detection range, m 1800
Sensor
Type uncooled
Resolution, pixels 640x480
Pixel pitch, um 17
NETD, mK <18
Frame rate, Hz 50
Optics
Objective lens F50 / 1.0
Magnification, x 2.5-10 (x4 digital zoom)
Field of view (HxV), degrees / m @ 100 m 12.4x9.3 / 21.8x16.3
Eye relief, mm 14
Display
Type AMOLED HD
Resolution, pixels 1024x768
Range Performance
Detection range, m 1800
Laser Rangefinder
Safety class for laser equipment according to IEC 60825-1:2014 1
Wavelength, nm 905
Max. measuring range, m 1000
Measurement accuracy, m ± 1
Video Recorder
Video / photo resolution, pixel 1024x768
Video / photo format .mp4 / .jpg
Built-in memory, GB 64
Wi-Fi
Wireless Protocol Wi-Fi
Wireless Standard IEEE 802.11 b/g/n/ac (WPA)
Frequency, GHz 2.4 / 5
Environmental Characteristics
Degree of protection, IP code (IEC60529) IP?7 (waterproof)
Operating temperature range, ° -25-+40
Connections and Compatibilities
Mount, type 1/4"
Dimensions, mm 238x72x90
Weight, kg 0.58 (w/o battery) / 0.72 (with the LPS7i battery)
|
