Sensor 1024x768 @ 12 µm (NETD <40 mK)
Objective lens F50 / 1.0
Magnification, x 2.5-20 (x8 zoom)
Field of view (HxV), degrees / m@100m 14x10.5 / 24.6?18.5
Detection range, m 2300
Sensor
Type uncooled
Resolution, pixels 1024x768
Pixel pitch, um 12
NETD, mK <40
Frame rate, Hz 50
Optics
Objective lens F50 / 1.0
Magnification, x 2.5-20 (x8 digital zoom)
Field of view (HxV), degrees / m @ 100 m 14x10.5 / 24.6?18.5
Eye relief, mm 14
Display
Type AMOLED
Resolution, pixels 1024x768
Range Performance
Detection range, m 2300
Laser Rangefinder
Safety class for laser equipment according to IEC 60825-1:2014 1
Wavelength, nm 905
Max. measuring range, m 1000
Measurement accuracy, m ± 1
Video Recorder
Video / photo resolution, pixel 1024x768
Video / photo format .mp4 / .jpg
Built-in memory, GB 64
Wi-Fi Wireless Protocol
Wi-Fi
Wireless Standard IEEE 802.11 b/g/n/ac (WPA)
Frequency, GHz 2.4 / 5
Environmental Characteristics
Degree of protection, IP code (IEC60529) IP?7
(Waterproof)
Operating temperature range, °-25-+40
Connections and Compatibilities
Supported Application Stream Vision 2
Power Supply
Output voltage, V 3.0-4.2
Battery type LPS 7i Li-Ion
Battery Pack
Capacity, mAh 6400
Operating time on battery pack (at t=22°C), h * 7
External power supply, V 5V, 9V (USB Type-C Power Delivery)
Weight & Size
Body material rubber armored reinforced plastic
Dimensions, mm 243x72x90
Weight, kg 0.73
|
